H-DMI To EDP LCD Driver Board

LCD Driver Board: HDMI to eDP Conversion Solution

Enhance your display with capabilities APTUS Technology's advanced LCD driver board. Designed to convert HDMI signals to eDP for LCD displays, our driver board offers exceptional performance and versatility.

Versatile Models for Diverse Display Needs

Our driver board is available in two models, each supporting different MONO LCD resolutions:

BHTE06 Program

- Supported Resolutions: 5K and 7K

- Technical Specifications:

  - 10.1" 5K:

    - Horizontal Resolution: 1640 tCLK

    - Vertical Resolution: 2880 tH

    - Frame Rate: 60 Hz

    - Pixel Clock: 317.740 MHz

  - 13.6" 7K:

    - Horizontal Resolution: 2160CLK t

    - Vertical Resolution: 3600 tH

    - Frame Rate: 30 Hz

    - Pixel Clock: 251.712 MHz

BHTE07 Program

- Supported Resolutions: 5K, 7K, and dual 8K

- Technical Specifications:

  - 10.1" 5K:

    - Horizontal Resolution: 1640 tCLK

    - Vertical Resolution: 2880 tH

    - Frame Rate: 60 Hz

    - Pixel Clock: 317.74 MHz

  - 13.6" 7K:

    - Horizontal Resolution: 2160 tCLK

    - Vertical Resolution: 3600 tH

    - Frame Rate: 30 Hz

    - Pixel Clock: 251.712 MHz

  - 10.1" 8K:

    - Horizontal Resolution: 2560 tCLK

    - Vertical Resolution: 4320 tH

    - Frame Rate: 30 Hz

    - Pixel Clock: 379 MHz

  - 16" 8K:

    - Horizontal Resolution: 2560 tCLK

    - Vertical Resolution: 4320 tH

    - Frame Rate: 25 Hz

    - Pixel Clock: 313 MHz

Why Choose Our LCD Driver Board?

- High-Resolution Support: Compatible with MONO LCD displays up to 8K resolution-

 Precision Timing: Optimized timing settings for different display sizes and resolutions

- Robust Performance: High-speed signal conversion with minimal latency

- Versatile Applications: Suitable for a wide range of applications including industrial displays, medical equipment, and digital signage

- Reliable Integration: Compact PCB structure for easy installation and integration

Technical Features

- HDMI to eDP Conversion: Efficient and reliable signal conversion

- Multiple Resolution Support: Single driver board supports various display resolutions

- High Frame Rates: Up to 60 Hz for smooth and responsive displays

- High Pixel Clocks: Supports pixel clocks up to 379 MHz for high-resolution displays
